耐蝕特點有優良抗還原性酸介質。特別是在高溫氟化氫氣體和氫氟酸溶液中有優良的耐蝕性，耐任何濃度氫氟酸溶液的腐蝕。主要應用于高溫氟化氫氣體和氫氟酸溶液工況，自動陰止流體倒流的閥門。止回閥的閥瓣在流體壓力作用下開啟,流體從進口倒側流向出口倒.當進口側壓力低于出口倒則,閥瓣在流體壓差本身重力等因素作用下自動關閉以防止流體倒流,廣泛適用于電站、化工、水力等行業。
The corrosion resistance features excellent resistance to reducing acid media. Especially in high-temperature hydrogen fluoride gas and hydrofluoric acid solution, it has excellent corrosion resistance and resistance to corrosion of any concentration of hydrofluoric acid solution. Mainly used in high-temperature hydrogen fluoride gas and hydrofluoric acid solution working conditions, automatic negative stop fluid backflow valve. The valve disc of a check valve opens under the action of fluid pressure, and the fluid flows from the inlet inverted side to the outlet inverted side. When the inlet side pressure is lower than the outlet inverted side, the valve disc automatically closes under factors such as the gravity of the fluid pressure difference itself to prevent fluid backflow. It is widely used in industries such as power plants, chemical engineering, and hydropower.
合金止回閥規格參數
Specification parameters of alloy check valve
壓力等級：
Pressure level:
公稱通徑：
Nominal diameter:
相對應的型號：H41W-10M、H41W-16M、H41W-25M、H41W-40M、H41W-63M、H41W-100TM、H41W-150Lb(M)、H41W-300Lb(M)、H41W-600Lb(M)、H44W-10M、H44W-16M、H44W-25M、H44W-40M、H44W-63M、H44W-100M、H44W-150Lb(M)、H44W-300Lb(M)、
Corresponding models: H41W-10M, H41W-16M, H41W-25M, H41W-40M, H41W-63M, H41W-100TM, H41W-150Lb (M), H41W-300Lb (M), H41W-600Lb (M), H44W-10M, H44W-16M, H44W-25M, H44W-40M, H44W-63M, H44W-100M, H44W-150Lb (M), H44W-300Lb (M)
適用介質：強腐蝕介質。
Applicable medium: Strong corrosive medium.
合金止回閥技術規范
Technical Specification for Alloy Check Valves
設計標準：GB/T12236、
Design standard: GB/T12236
結構長度：GB/T12221、
Structure length: GB/T12221
連接法蘭：HG、GB、JB、API、ANSI、ISO、BS、DIN、NF、
Connecting flanges: HG, GB, JB, API, ANSI, ISO, BS, DIN, NF
試驗標準：JB/T9092、GB/T13927、
Test standards: JB/T9092, GB/T13927
合金止回閥主體材料
Alloy check valve body material
M35-1、Monel400、MonelK500、
M35-1, Monel400, MonelK500
Thank you for reading. The source of this article is Lianggong Valve Agency. For more information and questions, please click on: http://www.bjstar-river.com We will continue to work hard to provide you with services. Thank you for your support!
